Arm Type Electronic Blood Pressure Monitor

Arm Type Electronic Blood Pressure Monitor

This blood pressure monitor is fully automated and measures quickly and accurately. The simple operating system and XL display make it possible to use it for either at home or on travel.

  • CE-marked medical device certified by TÜV Rheinland
  • One-button operation, fully automatic blood pressure and pulse measurement on the upper arm
  • For upper arm circumferences from 22 - 32 cm
  • Duo-user model is convenient for family use
  • 99 memories with time and date stamp for each user allows record tracking
  • The XL display with LED backlighting makes it easy to read the values on the screen, even in the dark
  • Use 4xAAA batteries for power. (Batteries are not included due to transport safety.)



Technical Details

Item Content
Classification Class IIa Medical Device
Protection against electric shock Internally powered, Type BF applied part(Cuff) Quasi-application section.LCD,Enclosure
Protection against harmful Ingress of water or particulate matter IP21
Mode of operation Continuous Operation
CUFF circumference Approx (220-320)mm
Weight Approx 300g (containing CUFF)
Physical Dimensions (Length*Width,Height) Approx (145*106*68.5)mm
Measure method Oscillographic measurement method
Measure Time <120s
Measuring range Pressure: 0~290 mmHg (0~38.66 kPa) Pulse number: 40~180 times/minute Systolic pressure: 8.0~34.0 kPa (60~255 mmHg) Diastolic pressure: 4.0-26.0 kPa (30-195 mmHg)
Measurement accuracy Blood pressure: ±3mmHg (±0.4kPa) Pulse number: Precision is ±5%
Automatic switch-off after 60 seconds in idle
Memory volume 99 records with time and date stamp
Normal working environment Temperature:+5℃~+40℃; Humidity: 15%-85%RH,Atmosphere: (80-106)kPa
Storage/transportation environment Temperature: -20℃~+55℃; Humidity: RHS93%,Atmosphere: (70-106)kPa
Voice function Support whole course mandarin voice broadcast
Automatic shutdown Automatic shutdown after 60 seconds without operation
Pressurization way Intelligent control of air pump automatic pressurization
Quick exhaust mode Intelligent control of automatic fast deflation
Pressure detection Resistive pressure sensor
Pulse detection Resistive pressure sensor
Battery Life Approx.300 uses when used 6 times a day with 4 new dry Batteries
Power source 4x1.5VAAdry Battery(Not Included)
Lifetime 5 years
EAN
